• Rating：3A 125VAC;1.5A 250VAC
• Contact Resistance：50mΩ Max
• Insulation Resistance：DC 500V 100MΩ Min
• Dielectric Strength：AC 1000V for 1 minute
• Operation Force：350±100gf
• Total Travel：3.0±0.5mm
• Operation Life：10,000 cycles
• Machanical Life：50,000 cycles Min
• Operation Temperation：0℃ ~85℃
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operation Force | Total Travel | Operation Life | Operation Temperation | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R0191A-10B-BR | 3A 125VAC;1.5A 250VAC | 50mΩ Max | DC 500V 100MΩ Min | AC 1000V for 1 minute | 350±100gf | 3.0±0.5mm | 10,000 cycles | 0℃ ~85℃ | 暫無(wú) |
| R0191A-10B-BB | 3A 125VAC;1.5A 250VAC | 50mΩ Max | DC 500V 100MΩ Min | AC 1000V for 1 minute | 350±100gf | 3.0±0.5mm | 10,000 cycles | 0℃ ~85℃ | 暫無(wú) |
| R0191B-10A-R | 3A 125VAC;1.5A 250VAC | 50mΩ Max | DC 500V 100MΩ Min | AC 1000V for 1 minute | 350±100gf | 3.0±0.5mm | 10,000 cycles | 0℃ ~85℃ | 暫無(wú) |
