• Rating：30VDC 0.1A
• Contact Resistance：50mΩ Max
• Insulation Resistance：100MΩ Min(250VDC)
• Dielectric Strength：250VAC（50/60Hz for 1 min）
• Operating Force：160±80g
• Electrically Life：100,000 cycles
• Operating Temperation Range：-20℃~+70℃
• Operating Mode：A：Self-Lock B：Non-Lock
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Electrically Life | Operating Temp. | Operating Mode | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| RPS58A(Self-lock) | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS58B | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS581A(Self-lock) | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS581B | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS582A(Self-lock) | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS582B | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS60A(Self-lock) | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS60B | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS70A(Self-lock) | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS70B | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS70A-1(Self-lock) | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS70B-1 | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS80A(Self-lock) | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS80B | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS851A(Self-lock) | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS851B | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS852A(Self-lock) | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS852B | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS8513A(Self-lock) | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
| RPS8513B | 30VDC 0.1A | 50mΩ Max | 100MΩ Min(250VDC) | 250VAC 50/60Hz for 1 min | 160±80g | 100,000 cycles | -20℃~+70℃ | A:Self-Lock B:Non-Lock | 暫無 |
